| Quantity: | |
|---|---|
Specification | Model | TS-PEC-003 |
Electrical Properties | Voltage | 230VAC ±10% |
Max Output Current | 16A(8/10/13/16 Optional ) | |
Frequency | 50/60 Hz | |
Max Output Power | 3.5kw | |
Residual current protection | 30mA AC | |
Structure Design | LED Indicator | 4 Indicators |
Charging Outlet | TYPE1/2 4.5M charging cable | |
Housing Material | PC+GF10% | |
Front Panel | PC | |
Security Protection | Safety Standard | IEC/EN 62752:2016 |
Multiple Protection | Over/llnder voltage protection, Surge protection, Over temperature protection, Over current protection, Leakage Protection, Short circuit protection, EFT Protection | |
Warranty | 1 year | |
Environmental Performance | Working temperature | - 30C~60C |
Storage temperature | - 40C~70C | |
Working humidity | 5%~95%, No condensation | |
Protection Level (control box) | IP65 | |
Altitude | <2000m | |
Application Site | Indoor/Outdoor | |
Cooling Method | Natural cooling | |
Packing Details | Product Size | 180*81*45mm |
Product Weight (Net Weight) | 《L9KG | |
Product Weight (Gross Weight) | 《2.2KG |
